Basic Bolt Design
Review Report
bolt Grade Shear Faces mm d = Bolt Information
Trb = kN kN Shear and Tensile Strength Vrb =
Shape Designation mm mm Gauge flange Width Gauge
kN Bearing Strength Br = Fu = MPa t = mm e = mm Fy = MPa


  Edge Distance
  1). Minimum end distance
    Le >= Tf / (0.75 Fu.t), and Le >= 1.5d
  2). Maximum end distance
    Le <= 12 t, and 150 mm

  Spacing of Bolts
  1). Minimum Spacing
    S >= Tf / (0.75 Fu.t) + d/2, and S >= 2.7 d
  2). Maximum Spacing
    S <= 24.t and 305 mm

mm Edge
